Description

AL series LiFePO4 – Lithium Iron Phosphate batteries.

Spec list

12V Batteries

12V Heated models

12V Lithium Batteries w/ Bluetooth BMS (except 20Ah model). Leisure Battery.

App can be downloaded here: SMART BMS for Android

App can be downloaded here for APP: APPLE app

60Ah | 75Ah | 80Ah | 100Ah | 120Ah | 150Ah | 200Ah | 300Ah | 400Ah | 24V 150Ah | 48V 100Ah – have bluetooth

20Ah model – does not have bluetooth function

Can be put in series up to 48V -unlimited parallel.

Limited five year warranty from date of purchase covers the purchaser/protects you against manufacturing defects. It does not cover negligence, improper use, natural expected changes in capacity or the operation of bluetooth (either the app itself or the connectivity to the app): – Please note, we can not ship these to the European Union, yet. We are working on getting this sorted.

12V 150Ah model is in the same box as the 120Ah battery. We have just managed to fit more cells into the same volume. Therefore, you get higher energy density.

Battery Information PDF – including Bluetooth We are constantly updating our battery range and specifications. The battery information PDF is prone to change. We endeavour to keep this updated.

Instructions

SMART BMS UPDATE information

12V 60Ah / 80Ah / 100Ah / 120Ah Lithium Iron Phosphate Battery with BMS and safety shutdown

general specs:

• LiFePO4 12V (nominal) 60Ah / 80Ah / 100Ah / 120Ah / 150Ah / 200Ah / 24V 150Ah 25 deg C Lithium Deep cycle
• Maximum continuous charge rate  = 50A / 60A / 70A / 80A /100A
• Maximum continuous discharge rate  =120A / 140A / 150A / 150A / 200A
• Battery must be safely charged within units parameters
• Max charge V=14.6V, Recommended =14.4V, Float V=13.8V
• Cut off voltage 11V / cutoff temperature 60 deg C
• Charge Curve style  CC/CV
• Operational temperature 0Deg to 60 deg C (adjustable)
• internal consumption: Operational = 10mA, Dormant 0.1mA
• 8mm ring terminal battery studs / washer
• Can be put in series 12V | 24V | 36V | 48V

E marking – E13 – only battery on UK market.

 THE BATTERY DIMENSIONS DOES NOT TAKE INTO ACCOUNT THE RING TERMINAL HEIGHT. PLEASE ADD RING TERMINAL AND BOLT HEAD HEIGHT TO THE DIMENSIONS

MSDS file – Hazmat

For the T1 DIN Standard Battery posts with 8mm thread. Positive and negative pair. They make a good addition if you wish to maintain legacy connections. Dimensions of the posts are below:
