LH4840
2,694.00 د.إ, excl. 5% VAT
48V 50Ah LiFePO4 – performance range. This battery is ideal for high charge / discharge current for power DC DC chargers and 2kW+ inverter loads. It has very good energy density as the battery is low volume. 48V 50Ah LiFePO4 – Lithium Iron Phosphate Battery w/ Bluetooth. 50A JBD – BMS This 50Ah battery is in a newer, more compact battery case. general specs: Battery power Weight of battery (kg) Dimension of battery (cm) 48V 50Ah 24 47.0L x 19.0W x 24H LiFePO4 12V (nominal) 50Ah 25 deg C Lithium
Description
48V 50Ah LiFePO4 – performance range.
This battery is ideal for high charge / discharge current for power DC DC chargers and 2kW+ inverter loads. It has very good energy density as the battery is low volume.
48V 50Ah LiFePO4 – Lithium Iron Phosphate Battery w/ Bluetooth.
50A JBD – BMS
This 50Ah battery is in a newer, more compact battery case.
general specs:
| Battery power | Weight of battery (kg) | Dimension of battery (cm) |
| 48V 50Ah | 24 | 47.0L x 19.0W x 24H |
- LiFePO4 12V (nominal) 50Ah 25 deg C Lithium Deep cycle
- Maximum continuous charge rate = 50A
- Maximum continuous discharge rate = 50A
- Battery must be safely charged within units parameters
- Max charge V=57.6V
- Cut off voltage 44V / cutoff temperature 60 deg C
- Charge Curve style CC/CV
- Operational temperature 0Deg to 60 deg C (adjustable)
- internal consumption: Operational = 10mA, Dormant 0.1mA
- 8mm ring terminal battery studs / washer
- Can be put in series 48V
- 0 Deg C charge circuit disconnect
- -20Deg C discharge circuit disconnect
- 50W heater built in for sub-zero charging.
Limited five year warranty from date of purchase. Warranty does not cover BlueTooth (Communication or app)
| Battery Capacity | 50 Ampere hour (50Ah) | 2560Wh LH4840 |
| Nominal Voltage | 48V |
| Heating Element | yes, 100W |
| Battery Chemistry | LiFePO4 Chemistry – Prismatic cells |
| Series Limit | 48v |
| Parallel Limit | Infinite |
| Dimensions and Weight | 47L x 19W x 24H (cm) – 18.4kg |
| Operating Temperature | Charge – 0’C to 60’C // Discharge from -20’C to 60’C – Integrated heater for low temperature operation |
| Operating Voltage | 51.2V (16S x 3.2V) |
| Charge Voltage | 56.8V-57.6V, 57.6V recommended |
| Float Voltage | 55.2V |
| Max Continuous Charge Rate | 1C (50A) |
| Max Continuous Discharge Rate | 1C (50A) |
| BMS Features | Bluetooth interface for battery information |
| Low temperature battery disconnect (0’C for charge, -20’C for discharge) | |
| Over voltage disconnect (14.8V or above on input) | |
| Low voltage disconnect | |
| Cell imbalance disconnect (Cell voltage differential of above 0.3V) | |
| Automatic cell voltage balancing | |
| Over current disconnect protection | |
| Short circuit protection | |
| Operational Quiescent Current | 10mA |
| Standby Quiescent Current | 0.1mA |
| Charge Curve | Constant Current / Constant Voltage – CC/CV |
| Terminals | M8 |
| Warranty | 5 years |
Additional information
| Weight | 18.4 kg |
|---|
