AC Input

90-270VAC // 45-65Hz, perfect for generator use

DC Input

130-320VDC

Efficiency

90.4%

Battery Chemistries

Suitable for all battery types within the voltage range. Lithium included.

Number of outputs

Dependent on model. PCU1210 has two outputs. All other models have three outputs.

Preset Battery Profiles

11 preset battery types, including 4x lithium presets. In the unlikely case none of our presets suit your batteries perfectly, we also have two custom profiles. One for lithium custom, one for lead acid custom.

Lithium Features

Live output voltage so as to offer the ability to wake up a dormant BMS Low temperature (0DegC) charge disconnect (In place of the temperature compensation featured on lead acid) A feed that allows your BMS to disable charge, with either a positive or resistance based connection

Operating Temperature

-40DegC to +60DegC

Approvals

UL, UKCA, CSA, CE, EN, TUV, CEC Compliant

Signal Output

0.25A signal output that mirrors the active output voltage, useful for signalling relays or other voltage based controls

Total Harmonic Distortion

2.4% on voltage and current

Display Accuracy

+/- 1% on voltage and current

Power Factor

0.976 at 230V

Warranty Period

Five years

Protections

Temperature sensor protections
Fan obstruction monitoring
DC High Voltage Trip
DC Low Voltage Trip
DC Output Fault (Reverse Polarity)
BMS shutdowns + ignition protection

Improved Ergonomics

A remote control with display is available. Code : PCUR

• Displays voltage, current.
• Multi-lingual
• Charging stage and duration
• Chosen battery type
• Temperatures
• Errors
• 3m of cable
